2.7K Low Light Imaging
The Falcon Y1LV2.0 night vision rifle scope uses a 2688 x 1520 low-light CMOS sensor with a 70 mm F2.0 objective lens. The 5x optical system is paired with selectable 5x, 10x, 15x and 20x digital zoom, a focus range from 5 m to infinity, and a 6.3 x 3.5 degree field of view.
1000 m Laser Rangefinding
The integrated laser rangefinder measures distances to 1000 m and displays ranging data on the screen. Ranging accuracy is +/-1 m, while the detection range is also 1000 m.
OLED Display and Optional IR Illumination
A 0.49-inch OLED display provides 1920 x 1080 resolution and supports Colour, Black and White, and Green viewing modes. Optional 850 nm or 940 nm IR configurations use a 5 W illuminator with a 200 m illumination distance.
Recording Controls and Connectivity
The scope records 1920 x 1080 video at up to 60 fps and supports MP4 video and JPG image files on a FAT32-formatted TF card. Wi-Fi connectivity supports wireless device functions, while raised physical buttons and the magnification lever provide direct control in the field.
Power Size and Protection
The 21700 lithium-ion battery specification is 5000 mAh at 3.6 V, with up to 5 hours of operating time. The scope measures 225 x 83 x 67 mm, weighs 574 g +/-5 g, is rated IP67 for water resistance and has a 10000 J shock-resistance rating.
Technical Specifications
| Specification |
Value |
| Brand |
Falcon |
| Model |
Y1LV2.0 |
| Product type |
Digital night vision rifle scope with laser rangefinder |
| Sensor |
Low-light CMOS |
| Sensor resolution |
2688 x 1520 |
| Objective lens |
70 mm F2.0 |
| Base magnification |
5x |
| Digital zoom |
5x / 10x / 15x / 20x |
| Exit pupil distance |
50 mm |
| Dioptre adjustment |
+5D to -5D |
| Focus distance |
5 m to infinity |
| Field of view |
6.3 x 3.5 degrees |
| Detection range |
1000 m |
| Laser rangefinding range |
1000 m |
| Ranging accuracy |
+/-1 m |
| Display |
0.49-inch OLED |
| Display resolution |
1920 x 1080 |
| Colour modes |
Colour, Black and White, Green |
| Optional IR wavelength |
940 nm / 850 nm |
| IR illumination distance |
200 m |
| IR illuminator power |
5 W |
| Battery specification |
21700 lithium-ion, 5000 mAh |
| Voltage |
3.6 V |
| Operating time |
Up to 5 hours |
| Dimensions |
225 x 83 x 67 mm |
| Weight |
574 g +/-5 g |
| Frame rate |
60 fps |
| Connectivity |
Wi-Fi |
| Storage |
TF card, FAT32 format |
| File formats |
MP4 video / JPG image |
| Video resolution |
1920 x 1080 |
| Water resistance |
IP67 |
| Shock resistance |
10000 J |
Installation Use and Care
- Install and zero the scope only in accordance with the firearm, mount and product manufacturers' instructions.
- Confirm that the scope and mount are secure before every use.
- Do not look into the laser aperture or direct the laser towards people, animals, vehicles or aircraft.
- Use the laser rangefinder and IR illumination only where lawful and follow all applicable local rules.
- Use a FAT32-formatted TF card for recording and allow files to finish saving before removing power.
- Confirm whether the selected product uses the optional 850 nm or 940 nm IR configuration before ordering.
- Keep optical surfaces clean with suitable lens-care materials and store the scope dry when not in use.
Frequently Asked Questions
What is the sensor resolution?
The Falcon Y1LV2.0 uses a 2688 x 1520 low-light CMOS sensor.
How far can the laser rangefinder measure?
The laser rangefinder measures to 1000 m with a ranging accuracy of +/-1 m.
What magnification settings are available?
The scope has 5x base magnification with selectable 5x, 10x, 15x and 20x digital zoom.
Which viewing modes are available?
The OLED display supports Colour, Black and White, and Green viewing modes.
Can the scope record video?
Yes. It records 1920 x 1080 video at up to 60 fps and supports MP4 video and JPG image files on a FAT32-formatted TF card.
What battery does it use?
The battery specification is a 21700 lithium-ion battery rated at 5000 mAh and 3.6 V, with up to 5 hours of operating time.
Which IR wavelength is available?
Optional 850 nm or 940 nm IR configurations are available. Confirm the required option before ordering.
Is the scope water resistant?
Yes. The housing is rated IP67 for water resistance.
